I thought it might be fun to do a kind of ride-along as I bust my knuckles getting the leaking heater core out of my ’02 Nissan Frontier – for the same basic reason that it’s more enjoyable to watch the running of the bulls than to actually run with the bulls.
To get at the heater core – which is basically a small radiator that warms the passenger compartment via warm engine coolant that circulates through it (and a fan/ductwork that blows/circulates the coolant-warmed air into the passenger compartment), it is first necessary to wrassle out of the way a plastic box that contains the AC evaporator. Which means first disconnecting the AC lines that feed it at the firewall. They are located just to the left of the heater core inlet/outlet tubes.
Ideally, get the AC system refrigerant evacuated before you do this. This requires specialized AC equipment which you probably won’t have unless you are an AC technician/professional mechanic – so you’ll probably need to take the vehicle to a shop to get the system evacuated and the refrigerant captured/stored so it can be put back into the AC system once everything’s buttoned up again.
I have a buddy who is a professional mechanic, so I was able to swing by his shop before I did any disassembly, to get the refrigerant out of the system.
Getting the evap box out is one of those things. As in: Are you ready for pain? Are you ready for suffering? If the Answer is yes, then you’re ready for Captain Freedom’s workout!
Chiefly because there is very little room to work in underneath the dash – because the space is tight and because everything’s packed in really tight. The box is only held in place by a few 10 mm bolts and all but one of them are easy to see and reach. The one you can’t see is invisible until you move the trim cover on the passenger side of the center console out of the way. Then you can slip a wobble extender bar through the mess to get at the last bolt.
Don’t forget to remove this one before you try to wrassle the box out because if you do, you will probably break the black plastic box trying to wrassle it out while it’s still partially bolted to the rest of the ductwork.
On my Nissan, this isn’t all that bad – in that it could be much worse. All I had to do to get at the heater (evaporator) box was remove the glovebox, which involved nothing more than removing the six screws that held the box in place. In some other vehicles, Step 1 is something like: Remove dashboard . . .
Once the heater/evap box is out, you will be able to see the heater core, which is off to the left and directly behind the center console on top of the drivetrain hump. You will also be able to see the two black plastic tubes that screw into the right side of the heater core and route from there to (and through) the firewall, where – if you’re like me – you earlier disconnected the rubber heater hoses and spliced them together so as to stop the gushing Niagra of coolant into the passenger compartment and all over the carpet. The ethylene glycol steam bath is especially good for the skin. And probably your lungs, too!
These black plastic tubes can be reused – assuming they’re not cracked and that’s not why you have coolant gushing into the passenger compartment and soaking your carpet with oily green goodness.
But should you reuse them?
I ruminated about this for a few days prior to actually tearing into the truck’s guts. The cheap (and po’) side of my brain said: Save yourself the money! Reuse those things! Then the smart side of my brain – such as it is – piped up and said: Do you want to risk having to do this job again? I ruminated not much longer. The plastic tubes aren’t broken/cracked or leaking. But they are 23 years old. Plastic gets brittle as it gets old and these particular pieces of plastic are subjected to hot coolant and then cool off – sometimes to freezing, if it’s that cold outside (and it sometimes is). It does to plastic what the sun does to a woman’s face. See her at 23. See here again 23 years later.
So – I ruminated – what are the odds those 23 year-old plastic tubes will not crack/break or leak in the years to come? Do I ever want to have to deal with the blankety-blank heater core again? To save probably $60?
I answered myself and will take a trip to the Nissan dealer for a pair of new tubes – which I gather are made of metal rather than plastic, as they ought to have been 23 years ago. That’ll be first thing Monday – when the dealer’s parts counter is open for business again – and after that, it’s just a matter of re-assembly, which is much less aggravating than disassembly. Chiefly because now you know how it all goes together – having taken it all apart.
Once the new core (and tubes) are installed and the box is back in place and everything else is buttoned up, I’ll have heat again as soon as I reconnect those two hoses I spliced together when the proverbial dam broke a week or so ago. Then it’s down to my buddy the mechanic’s shop to get the AC charged back up.
And ready to go for another 23 years!
. . .
